HJ-C10 series 12 healds cam shedding using for water jet loom for twill fabric

The cams used in HAIJIA cam shedding are constructed of Gr15, with a surface quenching hardness of HRC58-63, and are honed by theoretical calculation curve using a special grinder for cams imported from abroad, with a cam conjugation precision of 0-0.05mm. Different stopping angles can be made for wide weaving machines and specific types, which is more conducive to weft leading adjustment.
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • HJ-C10

  • HAIJIA

Positive conjugate cam shedding device, which is now widely used in water jet loom, air jet loom, rapier loom and other loom , can weave plain weave, twill weave, satin weave and other fabrics within twelve cycles.And till now it can help weave more than 150 varieties of fabrics. The shedding stop angle can be designed according to the weaving requirements of different looms. Compared with the crank shedding and the dobby shedding,it is more suitable for wide, heavy and high-speed weaving occasions, and has the characteristics of stability, high efficiency and energy saving.



No.

Max healds

Max weft cycles

machine width

Heald frame spacer

Max  speed

HJ-C10

12

12

150-360

14

750rpm

HJ-C20

10

12

150-360

14

900rpm

HJ-C21

14

7

150-360

12

700rpm

HJ-C30

10

12

150-360

14

900rpm

HJ-C50

10

12

150-360

14

1000rpm





*We use the latest Japanese equipment for processing. Compared with other brand, the machining precision of our parts used on the cam shedding device is more accurate.




*We have optimized and improved the structural which defects of their broken screws



*For the channel steel, Niupai Brand uses hot-rolled plates, which are then acid pickled and powder-sprayed. And we use acid pickling board, and then we electrophoresis and powder spray it to ensure it is not rusty.

 图片2图片3

*The work blanks and other parts of our cam box are all casted by the casting line, which is using in the automobile manufacture industry, and their precision, appearance and cost are different from other products



*Haijia cam parts are eIectrophoretic,cam box, lifting knife,cam sheet ,channel steel and so on ,these parts will not rust.
